FAN BLOWER REPAIR & RE-BUILD
Canadian Air Systems supply replacement parts to all industrialblower and fan makes:
- Replacement wheels, impellers for obsolete indutrial fans & blowers
- High temperature oven circulating fans repair & re-build
- Industrial fan / blower wheels balancing
- Stainless steel and other alloy fan & blower wheels / impellers duplication
- Custome blowers, fans, ventilators repair
for a number of industries and applications:
- industrial process air moving
- ovens and dryers air circulation
- dust collection, fume extraction and air scrubbing
- pneumatic conveying
- incinerators, flue gas exhaust
- combustion, industrial oxidizing
BLOWERS AND FANS WE SUPPLY:
- Combustion air supply blowers;
- Oven circulation fans;
- Pneumatic conveying blowers;
- Dust collector fans;
- Super high temperature fans;
- Material handling blowers;
- Exhaust and supply process fans.
- Combustion air supply blowers;
- Oven circulation fans;
- Pneumatic conveying blowers;
- Dust collector fans;
- Super high temperature fans;
- Material handling blowers;
- Exhaust and supply process fans.
Canada Blower Pressure Blowers have the following features:
- Complete AMCA fan performance & sound certification with capacities to 5,000 CFM @ 70" WG;
- Fan efficiency ... advanced wheel & aerodynamic housing combination for air-handling efficiency and low sound levels superior to conventional radial fan wheel designs;
- Stable Performance... the pressure curve remains stable from wide open to closed off... fan surge conditions, or pulsation, is eliminated even when turn-down approaches zero airflow;
- Versatility... various accessories, modifications, fan arrangements available: silencers, flexible connectors, acoustical cladding, air-tight sealed, spark-resistant & high-temperature construction, fan dampers...
OUR ANOTHER CANADA BLOWER PRODUCT - "BABY" PRESSURE BLOWERS:
... straight radial blades of heavy cast aluminum for self-cleaning feature, dynamically balanced for efficient operation
... AMCA tested and ASHRAE rated;
... arc-welded steel housings for rigidity and long life;
... designed for industrial applications such as: small exhaust systems where air is laden with dust or grit and also for supplying high pressure air for pneumatic conveying and cooling.
Canada Blower Narrow Pressure Blower Design:
These low CFM CENTRIFUGAL pressure blowers develop up to 75" WG in a single stage direct drive configuration, and up to 215" WG in two-stage configuration; all in a very economical Arr. 4 direct drive blower design.
All Canada Blower blowers are available in spark-resistant construction and with explosion proof motors.
Suppliers of industrial flue gas extractors and dust collection blowers, pneumatic conveying dust systems, material hndling air conveyors, industrial flue gas scrubbers and fume collectros.
Virtually every industrial process depends on a fan or blower but in many cases, heavy-duty industrial fans are needed opposed to low and medium duty units. Within the industrial fan category are many different types of fans.
Examples of Industrial Fans:
For example, pre-engineered fans have a range of blade shapes and being pre-engineered, they are typically a great cost-efficient choice. Pressure blowers are also commonly used, which are used primarily in combustion air applications as a means of blowing off air for drying and clearing applications.
There are also surge less blowers, which are high pressure, low volume units that do not surge as much as other fans. Because of this, extreme turndown is allowed without noticing major pulsation. Acid gas blowers are yet another option, which are very heavy-duty. These blowers are best suited for inlet pressures that range from full vacuum to 100 psig.
Sub-Fan Types: Industrial fans also come in many different subtypes :
Air Foil Fan – In this case, the fan has hollow air foil profiled blades. This fan design is excellent when quiet operation and high efficiency are mandatory. Typically, these fans provide continuous service where draft ventilating applications are needed to include industries like power generation, metals, rock products incineration, and so on.
Backward Curve Fan – This is another high-efficiency fan but because the design includes single thickness and curved plate blower blades, dust particles seldom build up. These industrial fans are most often used in high-pressure applications and provide excellent tip speed operation.
Backward Inclined Fan – In this case, the blades are flat and bent backwards slightly. As such, the velocity pattern of air that passes through the wheel is matched, thereby providing high-efficiency fan operation.
Radial Blade Fan – The blades on this fan are also flat but what makes them unique is that they are arranged in a radial pattern. Ranked as being “rugged”, these industrial fans usually have liners that are erosion resistant, which ultimately extends the life of the blower rotor.
Forward Curve Fan – Many people refer to these industrial fans as being squirrel cages. For the highest volume flow rate, this is the best fan. This type of centrifugal fan is commonly used in high-temperature furnaces but they also work great for a wide range of commercial and industrial HVAC applications.
Canada Blower Industrial aerofoil (AF) fan blower
SWSI, DWDI, AcF, PLR, BI, BC, AF, ST, Backward Inclined, Aerocline, General Purpose, GP, BL, Limit Load, LL, Canada Blower Buffalo Vent Set, BCV, BCA, BCM, BCS: industrial aerofoil fan blowers are supplied in welded heavy gauge steel construction to prevent flexing at high pressure. Available in direct drive arrangements 4/4V/4H/7/8 and belt drive arrangements 1/3/9/10. Arr. 10 blowers are known as ventilating sets (vent sets). Available in single width single inlet (SWSI), or double width double inlet (DWDI). Capacities: to 500,000 CFM. Static pressure up to 100 inches water gauge depending on the class of construction. Typical class of construction is Class 1, 2, 3, 4, 5.
Canada Blower Tubular Inline Fans combine the efficient performance of centrifugal airfoil wheels with the versatility and compactness of axial-flow fan design. Uses include industrial / process supply and exhaust applications as well as heating, ventilating and air-conditioning systems.
Canada Blower Fan Wheel Design: backward Inclined-Airfoil and Backward Inclined-Single Thickness fan blades.
